Contents
3
Clearing a Misfeed from the Paper Feeding Tray ............ 3-14
Clearing a Misfeed from the Paper Cassette .................... 3-15
Clearing a Misfeed from inside the Printer ...................... 3-16
Clearing a Misfeed from output bin ................................. 3-18
Chapter 4 MSP 3000 Printer ............................................... 4-1
1. Parts of the Printer ................................................................. 4-2
2. Paper Specifications ............................................................... 4-4
Use only the following types of paper ............................... 4-4
3. Set the Paper .......................................................................... 4-5
Loading Paper into the Paper Feeding Tray ...................... 4-5
Loading Paper in the Paper Cassette .................................. 4-6
4. Replacing the Toner Cartridge ............................................... 4-7
5. When the Paper Misfeed Indicator Lights Up ....................... 4-9
If the Misfeed Indicator lights up along with a P0 code: ... 4-9
If the Misfeed Indicator lights up along with a P1, P2 or P3
code: ................................................................................... 4-9
Clearing a Misfeed from the Paper Feeding Tray ............ 4-10
Clearing a Misfeed from the Paper Cassette .................... 4-11
Clearing a Misfeed from inside the Printer ...................... 4-12
Chapter 5 Troubleshooting.................................................. 5-1
1. Solving Irregular Printing Problems ...................................... 5-2
Chapter 6 Maintenance........................................................ 6-1
1. System Care ........................................................................... 6-2
Cleaning the Scanner Screen ............................................. 6-2
Outer Covers ...................................................................... 6-2
Carrier Glass (Option) ........................................................ 6-2
Cleaning the System Printer (Option) ................................ 6-3
Cleaning the MSP 3500 Printer ......................................... 6-3
Cleaning the Printer Exterior ............................................. 6-4
Cleaning the Printer Interior .............................................. 6-4
Paper Pickup Rollers .......................................................... 6-5
Cleaning the MSP 3000 Printer ......................................... 6-8
Chapter 7 Miscellaneous ...................................................... 7-1
1. Specifications ......................................................................... 7-2
PC Mode ............................................................................ 7-3
PR Mode : MSP 3500 Printer ............................................ 7-3
