8
2.3 Replacing Grille Pins
The grille pins installed on the grille assemblies are fragile and can be easily
damaged. Should any of the pins break, you may replace them using the
following procedure.
1. Place the grille assembly face-down on a padded surface (a towel or
carpeting).
2. Remove the damaged grille pin by pulling it straight out with a small pliers
or similar tool. Please refer to figure 2.4. Make sure that the complete pin is
removed and that there are no pin fragments left in the mounting hole.
3. Insert the new grille pin in the grille pin installation tool (see figure 2.5).
Figure 2.4 - Removal of broken grille pin. Check for pin fragments in
the mounting hole.
Figure 2.5 - Insertion of new grille pin into installation tool.
