6
2.1 Opening the Crate
The crate features a one-piece top assembly which is fastened to the crate
bottom with screws around the lower perimeter. To unpack, remove the
screws and lift the upper portion of the crate straight up (this will require two
people).
Next, slide each speaker part way off of the crate base so that the plastic
bag can be unfastened from the enclosure bottom. Please note that the
binding post is on the back of the speaker. Be sure to slide speaker to end
and not the side. Stand the speaker up and the bag can be pulled off the
top. Please refer to Figure 2.1.
Figure 2.1 - To unpack the loudspeakers.
1. Remove screws.
2. Lift case.
3. Slide speaker,
then undo bag.
4. Stand speaker up,
then remove bag.


