magnitude

format

that

varies

from

0=1.00

at

the

top

of

the

display

(100%

re ection)

to

0.00

at

the

bottom

of

the

display

(perfect

match).

Standing

W

ave

Ratio

T

o

display

the

re ection

measurement

data

as

standing

wave

ratio

(swr ),

press

4

F

ormat

5

NNNNNNNNNNN

SWR

.

The

analyzer

reformats

the

display

in

the

unitless

measure

of

SWR

(with

SWR

=

1,

a

perfect

match,

at

the

bottom

of

the

display).

Figure

5-14.

SWR

Network

Measurement

Examples

5-15
