Corn cooker, Replacement parts – A.J. Antunes & Co CCC-20T 9600220 User Manual
Page 11
11
CORN COOKER
P/N 1010946 Rev. A 09/06
REPLACEMENT PARTS
1 0800380 Basket, Corn
2
2 0504108 Clamp, Heater
1
3 403K121 Thermostat Kit (Incl. #20)
1
4 0504106 Clamp
1
5 0021471 Base Plate Weldment
1
6 210K230 Bumper Leg Kit (Incl. Qty. 4 Legs)
1
7 2100106 Handle, Grip
1
8 0504112 Housing, Base
1
9 0021470 Pan Weldment
1
10 401K106 Rocker Switch, Power On/Off,
230V (Incl. #12)
1
401K107 Rocker Switch, Power On/Off,
120V (Incl. #12)
1
11 4030369 Element, Heating 1920W, 230V
1
12 0400291 Splashguard
1
13 4060315 Indicator Light, Green, 230V
(Mfg. Nos. 9600202)
1
4060331 Indicator Light, Green, 120V
(Mfg. Nos. 9600200)
1
14 1001198 Label, Head Housing
1
15 0021469 Head Housing Weldment
1
16 0700453 Power Cord, CEE 7/7
1
17 040K251 Strain Relief Kit
1
18 0504555 Panel, Access
1
19 7000136 Terminal Block
1
20 020K195 Gasket Seal Kit
(Incl. plate cover inner, plate cover
outer, gasket seat and Qty. 2 screws) 2
21 0400290 Insulator, Electrical
2
22 401K101 Interlock Switch Kit (Incl. #24)
1
23 1001199 Label, Wiring Diagram
1
24 020P115 O-Ring
1
25 306P102* Washer, Internal Tooth, #6
1
26 306P104* Screw, #6-32 x 1/4”
1
27 306P105* Screw, #6-32 x 1/2”
1
28 306P107* Nut, Hex, Acorn, #6-32
1
29 306P108* Screw, $6-32 x 1”
1
30 306P123* Screw, #6-32 x 7/8”
1
31 306P130* Nut, Hex, KEPS, #6-32
1
32 308P103* Screw, #98-32 x 1/4”
1
33 308P115* Screw, #8-32 x 3/8”
1
34 308P124* Screw, One-way, #8-32 x 1/2”
1
35 308P143* Nut, Hex, KEPS, #8-32
1
36 310P102* Lockwasher, #10
1
37 310P123* Screw, #10-24 x 1/2”
1
39 310P146* Nut, Hex, KEPS, #10-32
1
NS 0011046 Base Housing Assy.
1
0011769 Base Housing Assy.
1
NS 406P107* Cable Ties
1
40 4070093 CCC-20T Control Board
1
40a 00202-0330 Assy-PCB, CCC-20 Beeper
1
* Only available in packages of 1
0.
Item Part No.
Description
Qty.
Item Part No.
Description
Qty.
