56
-C -C -N -N -A -A
3. Products - thread turning
CoroCut® XS – external threading
For precision threading in small part machining, up to 32 mm (1.26
inch) diameter. CoroCut XS is used ideally where the tool is close to
the shoulder of the workpiece and in sliding head machines. Also
for parting, grooving and turning.
• All inserts fi t into the same tool holder
• Easy indexing and good accessibility when changing inserts
• Sharp cutting edges
• Low cutting forces
With insert types A and C, threads can be machined
very close to the component.
MATR right-hand
cutting insert/tool
holder. MATL left-hand
cutting insert/tool
holder. All inserts fi t into CoroCut XS shank
holders. Three types of insert: C, N
and A.
C = Left hand
N = Neutral
A = Right hand
