Chapter 3
Replaceable Parts
Introduction
This chapter contains information for ordering replaceable parts for the
E1364A Switch Modules with serial number 2934A10370 and higher.
The tables provide the following information:
•
Table 3-1 lists assembly and terminal module part numbers for the
E1364A Switch Module.
•
Table 3-2 lists the Reference Designators for the switch module.
Ordering
Information
To order a part listed in Table 3-1, specify the Agilent part number and the
quantity required. Send the order to your nearest Agilent Technologies
Sales and Support Office.
If your E1364A Switch Module has a serial number prior to 2934A10370,
see Appendix B, "Backdating Information," for replaceable parts
information.
Replaceable Parts Lists
See the Parts Locator Diagrams (Figures 3-1 and 3-2) for locations of
replaceable parts.
Table 3-1. E1364A Replaceable Parts (serial number 2934A10370 and higher)
Reference
Designator
Part
Number
Qty Part Description
E1364-66201 1 COMPONENT ASSEMBLY
BRK1-BRK2
F1
F2
J1
LBL1
LBL2 0050-2183
2110-0936
2110-0936
1252-1591
E1300-84308
E1300-84312 2
1
1
1
1
1 BRKT-PNL MNT
FUSE 4A 125V SMT
FUSE 4A 125V SMT
CONNECTOR-RA PL, 48P
LBL LOGO B SIZE
LBL-LOGO VXI B SIZE
K100-K115
MP1-2
P1
SCR1-2
SCR3-4
SHD1
SW1 0490-1912
1400-1546
1252-1596
0515-0444
0515-1968
E1300-80601
3101-3142 16
2
1
2
2
1
1
RELAY-ARMATURE HiR, Low E
BRACKET PC BOARD HOLDER; BLACK; EXTRUDED
CONNECTOR-POST TYPE 2.54-PIN-SPCG 96-CONTACT
SCREW- X 8MM-LG -HD
SCR PHM 2.5 X 11 TX
SHIELD SAFETY
SWITCH-DIP 8 - 1A SMTV
E1364-80001 1 TERMINAL MODULE
E1364-66510
E1300-84401 1
1 TERMINAL CARD 16-CH GP RLY SWITCH
TERMINAL CARD, CASE ASSY
