Aviom A-16II Personal Mixer User Guide
16
procedure; turn the T
REBLE
knob right to add highs, left to diminish them.
The Bass and Treble EQs in the Personal Mixer are both shelving type.
There is +/-12dB of cut or boost available for each.
Bass EQ 160Hz shelving
Treble EQ 9kHz shelving
+12dB
-12dB
+12dB
-12dB
160Hz 9kHz
Master Volume
The overall system volume is controlled by the M
ASTER
volume control.
This is an analog-style control. Turn it counterclockwise for a full off
setting. As a general suggestion, start with the Master volume knob at a low
setting, about 9 or 10 o’clock to start. Raise the volume slowly from that
point to a comfortable listening level.
Note: Always use caution when adjusting any audio system component to
avoid potential hearing damage.
Button Behaviors
There are various combinations of lighted and unlighted buttons on the
A-16II Personal Mixer. Here is an overview:
• Channel buttons have two LEDs, an upper and lower.
The upper button is red and indicates that the Channel is
selected. The lower button is yellow; it indicates that the
Channel is muted. Channel buttons will light solid or flash.
• The R
ECALL
button has one red LED. It flashes when the
R
ECALL
button is pressed, indicating that you can now select
a Preset by touching any numbered button.
• There is one LED in the G
ROUP
button. When the G
ROUP
button is pressed, the LED flashes. This indicates that you
can now build or edit a Group.
• The R
ECALL
and G
ROUP
buttons will both flash when held
down simultaneously. This is the Save Mode, as indicated
by the connecting graphic above the two buttons on the front
panel.
• When a Preset is saved, all sixteen Channel buttons will
flash briefly to confirm the Preset save operation.
