Chapter 3 PS-A Monitoring Features
3-27
3.8
Setup Guide for the System Monitor Property
The System Monitor Property allows you to specify PS-A items you want to monitor with the RAS features
and the notification method used when errors/alerts occur.
When an error/alert occurs, notification is provided according to the method specified in the System Monitor
Property.
The following table lists the operating settings that can be configured for each feature.
O: Setting available X: Setting not available
The following table lists the default settings of each feature.
O: Setting available X: Setting not available —: Not supported
•
For procedure to set up the System Monitor Property, refer to the following section.
•
You can check the status of the PS-A unit you are monitoring with the RAS features on the
System Monitor screen.
For details regarding the System Monitor screen, refer to the following.
Feature
Operation
Buzzer
Popup
Message
OS
Shutdown
LED
DOUT0 to
3
Reset
Timeout
(sec):
Backlight
O
O
X
O
O
X
X
DIN0-3
O
O
O
O
O
X
X
Fan
*1
*1
Nothing is displayed on PS-3711A.
O
O
O
O
O
X
X
Remote Reset
X
X
X
X
X
O
X
SMART
O
O
X
O
O
X
X
Temperature
O
O
O
O
O
X
X
Voltage O
O
O
O
O
X
X
Watchdog Timer
O
O
O
O
O
O
O
• Administrator Authentication is required for executing SMART Monitoring. When a
user who does not have the administrator authentication logs in, nothing is
displayed in the item of SMART.
Feature
Operation
Buzzer
Popup
Message
OS
Shutdown
LED
DOUT0 to
3
Reset
Timeout
(sec):
Backlight
X
O
—
O
X
—
—
DIN0-3
X
O
X
O
X
—
—
Fan
*1
*1
Nothing is displayed on PS-3711A.
X
O
X
O
X
—
—
Remote Reset
—
—
—
—
—
O
—
SMART
X
O
—
O
X
—
—
Temperature
X
O
X
O
X
—
—
Voltage X
O
X
O
X
—
—
Watchdog Timer
X
O
X
O
X
X
O(5sec)
SEE
3.3.2 Setup Procedure (page3-10)
