PL3000 Series Hardware Manual
4-22
4.5.2
Dimensions of the 4 slot Unit (Installation fasteners attached)
Unit: mm [in.]
Top
DISPLAY AREA
CENTER
PRODUCT
CENTER
462 [18.19]
352 [13.86]
441 [17.36]
488 [19.21]
26.5 [1.04]
21 [0.83]
367 [14.45
]
3
1
3
[1
2.
32
]
218 [8.58]
2 [0.08]
10 [0.39]
33
4 [13
.1
5
]
2
80 [1
1.02]
Front
Side
