SpitFIRE Innotech Systems Inc. Page 8
LEARNING IR CODES
SEND CODE RESPONSE
SOURCE 1-4 1 GREEN FLASH
LEARN RED AND GREEN LEDs WILL LIGHT
SEND DESIRED BUTTON CODE. (IF USING
SUPPLIED SOFTWARE, CLICK ON DESIRED
BUTTON )
GREEN LED WILL GO OUT
HOLD ORIGINAL REMOTE CLOSE TO
SPITFIRE II WHILE AIMING IR LED ON
REMOTE AT IR SENSOR ON SPITFIRE.
PRESS DESIRED BUTTON ON ORIGINAL
REMOTE
RED LED WILL GO OUT, GREEN LED WILL
FLASH
Erasing Learned Codes
Learned functions are associated with the selected
source (TV, VCR etc.). To erase learned functions
for a specific device TV, VCR etc.), you
overwrite the learned code with a code from the
code library. You can erase the complete device;
individual buttons cannot be erased.
1. Select the device you wish to reprogram by
sending the appropriate Source Code (TV, VCR,
Cable etc.). For instance to erase the learned
buttons associated with the VCR, send the Source
Code you have associated with the VCR.
The Program LED will flash once.
2. Send the scancode for Program (40h).
The Program LED will flash twice.
3. Select a 3-digit ISI device code number from
the code list and send the 3-digit code. The
Program LED will flash once for each key
pressed.
4. Send the scancode for Program (40h) again to
lock in the code. The Program LED should flash
3 times. The VCR function will now operate per
the selected device code without any learned
buttons.
