SpitFIRE Innotech Systems Inc. Page 10
Subsequently, when a button release command is
sent, the SpitFIRE completes the current
transmission and then it returns the appropriate
status.
Special scancodes are available to tell the
SpitFIRE to transmit IR message until told to
stop, or to send messages a fixed number of times.
The auto-repeat range is from 1 to 8 messages. A
setting of 0 tells the SpitFIRE to send the
message continuously until the button is released.
When the transmit N times feature is used, the
SpitFIRE will not return a status byte until the IR
transmission is completely sent (N times) so that
the system knows that the transmission is
complete.
The following is a list of scancodes that a system
can send to the SpitFIRE . Codes are in
hexadecimal and do not include the button-
pressed bit.
Code Code Function Notes
0 00h #0
1 01h #1
2 02h #2
3 03h #3
4 04h #4
5 05h #5
6 06h #6
7 07h #7
8 08h #8
9 09h #9
10 0Ah ENTER
11 0Bh MUTE
12 0Ch VOL+
13 0Dh VOL-
14 0Eh CH+
15 0Fh CH-
16 10h REWIND
17 11h PLAY
18 12h FF
19 13h RECORD
20 14h STOP
21 15h PAUSE
22 16h POWER
23 17h RECALL
24 18h TV/VCR
25 19h DISPLAY
Code Code Function Notes
26 1Ah REPEAT
27 1Bh RANDOM
28 1Ch MODE
29 1Dh DISC
30 1Eh SEL1
31 1Fh SEL2
32 20h SEL3
33 21h SEL4
34 22h SEL5
35 23h SEL6
36 24h SEL7
37 25h SEL8
38 26h SEL9
39 27h SEL10
40 28h UP
41 29h DOWN
42 2Ah LEFT
43 2Bh RIGHT
44 2Ch TRACK UP
45 2Dh TRACK DOWN
46 2Eh SKIP UP
47 2Fh SKIP DOWN
48 30h INDEX UP
49 31h INDEX DOWN
50 32h TRACK
51 33h GROUP
