PAT-CP-0245 Catalyst Pump Manual
Rev. 03/2013
Page | 17
Introduction:
WARNING
Please observe all warnings before performing any maintenance
Follow the pressure relief procedures in this manual.
Use proper safety gear, gloves and safety glasses.
Turn off electrical equipment associated with system
Clean all tools to be used of grease or other material that can react with MEKP
Tools needed for removal and repair of Catalyst pump.
• 8” Adjustable wrench (08467)
• 6” Adjustable wrench (08466)
• Flat head screw driver
• 5/64” Allen wrench (9301-1-2) or (Allen wrench set 8469)
• Straight scribe (08126)
Seal kit #: PAT-CP-0245-SK
Note: If flushing the complete catalyst system from catalyst jug to gun is desired
before working on system, use only distilled water.
