GeneralAire Remote Wall Blower - Manual (Page 9)

9
description value or range
steam output (lb/hr) 0-12
storage temperature (
C)
-10 to 70
rated power (W) 24
rated air flow-rate (cfm) 71
noise level (open field, at maximum speed, one metre from the front panel) (dB) 30
9. RMB GRILL INSTALLATION
10. MAINTENANCE
Attach the air filter to the grill, install the grill over the housing face and use the provided screws and
pre-drilled holes to secure the grill to the RMB housing. The steam manifold will extend out past
the face of the grill. The grill may be painted to match decorations in the home.
NOTE:
1. Use only the grill that was provided with the RMB kit. Any alterations or changes to the
grill may result in water leakage and damage to the home.
Air filter maintenance is essential for maintaining a constant flow of air to the distributor. Neglect-
ing the air filter (cleaning and/or replacement) will seriously effect the operation of the RMB unit.
Maintenance is the responsibility of the user. The air filter should be vacuumed or rinsed with
water at least once per year. More frequent cleaning may be necessary.
Note:
For new construction, the air filter must be cleaned as needed during construction and
again when construction is compete
11. STARTUP
12. TECHNICAL SPECIFICATIONS
13. TABLE OF SPARE PARTS
The RMB blower will operate when the humidifier has a demand for humidity. Operation will con-
tinue for 30 seconds after the demand is complete.
O rder Part
Num ber Num ber Part Nam e
7545 RM B15 Rem ote M ount Blower Kit
7540 RM B35 Rem ote M ount Blower Kit
7534 15-02 Room Blower Assem bly 110v for RM B15
7535 35-02 Room Blower Assem bly 240v for RM B35
7513 20-2 Steam Hose 7/8” ID
7512 20-3 Condensate Hose 3/8” ID
7559 35-10 Hardware kit (RM B15/RM B35)
7536 35-20 Internal steam distributor m anifold
7528 35-26 Front G rill for RM B (includes filter, labels)
35-27 RM B Installation Instructions
7647 P-241 Steam Hose Clam p #16
7648 P-242 Condensate Hose Clam p #6
