GeneralAire Remote Wall Blower - Manual (Page 6)

6
6. INSTALLATION
Insert the RMB housing into the wall and bend the four securing tabs around the back of the
drywall. Secure the RMB housing to the wall using predrilled holes located on the four one-inch
flanges of the RMB unit. Use #8 drywall screws (four required) to penetrate the wall and pass
through the slot in the securing tab behind the drywall.
Note:
1. The four one-inch flanges on the face of the RMB unit must be on the outside of the
drywall. Failure to locate the flanges on the outside face of the drywall may result in water
leakage and household damage.
Fig 6.1
-SECURING TABS
WITH SCREW SLOT
4 PLACES
PRE-DRILLED-
SCREW HOLES
FOR WALL.
