OmniAccess 4324: Installation Guide
24 Part 031640-00 May 2005
Cables
The following table lists the cable characteristics for approved GBICs:
T ABLE 3-2 GE Cable Characteristics
GBIC Type Characteristics
1000BASE-T (copper) Cable:
Connect
or:
Range:
Category 5 UTP
RJ-45
Up to 100 m (325 feet)
1000BASE-SX
(optical)
Shortwave 850 nm Cable:
Connect
or:
Range:
62.5 µm multimode fiber
SC-type fiber optic
Up to 260 m (850 feet)
Cable:
Connect
or:
Range:
50 µm multimode fiber
SC-type fiber optic
Up to 550 m (1800 feet)
1000BASE-LX Cable:
Connect
or:
Range:
9-10 µm singlemode fiber
SC-type fiber optic
Up to 10km (6.21 miles)
Cable:
Connect
or:
Range:
62.5 µm multimode fiber
SC-type fiber optic
Up to 550 m (1800 feet)
C AUTION —Be sure to follow the instructions and notifications in “Laser
Notice” on page iv.
