IMP Pumps NMT(D) 40-100 & NMT SAN flanges User Manual
Page 19
GB
-19-
connection functions (Fig. 2)
Markings
Descriptions
L
230V AC, electricity power supply.
N
PE
Safety ground.
FC
Ferrite core for HF interference compliance. PE, L and N wires should
be lead thru it. (Part is in the package with cable glands).
NC
Normally closed relay contact.
C
Common relay lead.
NO
Normally closed relay lead.
IO2
Digital input 2.
24V
+24V@100mA max.
GND
Digital input common return.
IO1
Digital input 1.
ETHERNET
Ethernet connection.
The pump has a built-in over current fuse and protection, temperature protection and basic
overvoltage protection. It does not need additional thermal protection switch. Connection leads
should be capable of carrying rated power and properly fused. Ground lead connection is
essential for safety. It should be connected first. Grounding is only meant for pump safety. Pipes
should be grounded separately.
4. p
ump
installatiOn
4.1
i
nsTallaTion
inTo
pipe
lines
Pump is protected with a double box during transport. It can be lifted from the box with internal
handles or by lifting it by the heat sink.
Pumps might be heavy. Provide yourself help if needed.
Pumps are designed to be built in connecting flanges. Use all screws. The connecting flanges
are designed for nominal pressure PN 6/10.
Ambient and medium permissible temperatures
Ambient temperature
[C°]
Maximum medium temperature
[C°]
do 25
110
30
100
40
90
