BabyTrend FB60408 - TRENDZ FASTBACK 3-IN-1 CAR SEAT - JELLY BEAN - Manual (Page 10)

17 18
5.2 High-back Booster Seat WITHOUT
Built-in Safety Harness
Your child must meet ALL these requirements:
• Weight between 30 and 100
lbs (13.6 and 45.3 kg)
• Height between 38 and 57 inches
(96 and 145 cm)
• Approximately 3-10 years of age
• The shoulder belt MUST lie
across child’s shoulder as shown
and the lap portion of the belt is
positioned low on the child’s hips
• Child’s ears are BELOW
top of the booster seat
Note: If the tops of the ears
are above the top of the seat, then the
child is too large for the booster seat.
Parents are advised that the back support and head support of the high-
back booster car seat provide incremental crash protection in frontal
and side impact crashes. Removing the back support and head support
earlier than necessary also removes the incremental crash protection.
We highly recommend using the built-in safety harness for
as long as possible when the child is 70 lbs or less and the
shoulders are below the harness slots in the highest position.
5.1 Toddler Car Seat WITH Built-in Safety Harness
Your child must meet ALL these requirements:
• Weight between 22 and 70
lbs (10 and 31.7 kg)
• Height between 28.5 and 52 inches
(72 and 132 cm)
• At least one year old and
can sit upright unassisted
• Top of child’s shoulders are at
or BELOW harness slots in
highest adjustment position
Note: If child’s shoulders are above
the harness slots when adjusted to
the highest position, child is too large
to use Built-in Safety Harness.
5.0
Height and Weight Limitations
5.0
Height and Weight Limitations
