MAX9519
1mm x 1mm Video Filter Amplifier with
Automatic Shutdown and 4V/V Gain
6
_______________________________________________________________________________________
Pin Description
PIN
NAME
FUNCTION
A1
GND
Ground
A2
OUT
Video Output
B1
IN
Video Input
B2
V
DD
Positive Power Supply. Bypass V
DD
with a 0.1µF capacitor to ground.
CURRENT
DAC
VIDEO ENCODER
NO VIDEO
SIGNAL
A
V
= 4V/V
OUT
IN
BUFFER
LPF
AUTOMATIC
SHUTDOWN
CONTROL LOGIC
MAX9519
V
DD
+3.3V
GND
1.8
μA
75
Ω
Figure 1. Automatic Shutdown
DISABLE TIME
MAX9519 toc19
40
μs/div
IN
500mV/div
OUT
500mV/div
ENABLE TIME
MAX9519 toc18
10
μs/div
IN
500mV/div
OUT
500mV/div
Typical Operating Characteristics (continued)
(V
DD
= 3.3V, GND = 0V, DC-coupled input, video output has R
L
= 150Ω connected to GND, T
A
= +25°C, unless otherwise noted.)
