MAX9519
1mm x 1mm Video Filter Amplifier with
Automatic Shutdown and 4V/V Gain
2
_______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V
DD
= 3.3V, video output has R
L
= 150Ω connected to GND, T
A
= T
MIN
to T
MAX
, unless otherwise noted. Typical values are at
T
A
= +25°C.) (Note 1)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
(Voltages with respect to GND.)
V
DD
.................................................................................0 to +4V
IN ............................................................................. -0.3V to +4V
OUT (during shutdown)............................. -0.3V to +V
DD
+ 0.3V
Continuous Current
IN ...................................................................................±20mA
Continuous Power Dissipation (T
A
= +70°C)
4-Bump UCSP (derate 3mW/°C above +70°C).............239mW
Maximum Output Current
OUT ................................................................................±100mA
Operating Temperature Range .........................-40°C to +125°C
Junction Temperature ......................................................+150°C
Storage Temperature Range .............................-65°C to +150°C
Bump Temperature (soldering)
Infrared (15s) ................................................................+220°C
Vapor Phase (60s) ........................................................+215°C
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Supply Voltage Range
V
DD
Guaranteed by PSRR test
2.7
3.6
V
Automatic shutdown
mode
No load, IN does not
have an active video
signal
1.8
4
Active-detect mode
No load, IN has a
black-burst video
signal with a sync tip
at GND
5.4
µA
Supply Current
I
DD
R
L
= 150
Ω connected to GND, IN has a
black-burst video signal with a sync tip,
quiescent current only; no load current is
included
2.9
4.8
mA
AUTOMATIC SHUTDOWN
Minimum Line Frequency
7.3
kHz
Sync Slice Level
1.7
3.0
%V
DD
Output Load Detect Threshold
200
Ω
DC CHARACTERISTICS
2.7V
≤ V
DD
≤ 3.6V
0
0.525
Input Voltage Range
Guaranteed by
output-voltage swing
3.0V
≤ V
DD
≤ 3.6V
0
0.6
V
Input Current
I
B
IN = GND
1
5
µA
Input Resistance
R
IN
20
M
Ω
DC Voltage Gain
A
V
G uar anteed b y outp ut- vol tag e sw i ng ( N ote 2)
3.92
4
4.08
V/V
Output Level
IN = GND
0.18
0.325
0.475
V
V
DD
= 2.7V,
0
≤ V
IN
≤ 0.525V
2.058
2.1
2.145
Output-Voltage Swing
Measured at output
V
DD
= 3.0V,
0
≤ V
IN
≤ 0.6V
2.352
2.4
2.450
V
P-P
