MAX9519
1mm x 1mm Video Filter Amplifier with
Automatic Shutdown and 4V/V Gain
4 _______________________________________________________________________________________
SMALL-SIGNAL GAIN
vs. FREQUENCY
MAX9519 toc01
FREQUENCY (MHz)
NORMALIZED GAIN (dB)
10 1
-60
-50
-40
-30
-20
-10
0
10
-70
0.1 100
V OUT = 100mV P-P
SMALL-SIGNAL GAIN FLATNESS
vs. FREQUENCY
MAX9519 toc02
FREQUENCY (MHz)
NORMALIZED GAIN (dB)
10 1
-7
-6
-5
-4
-3
-2
-1
0
1
2
-8
0.1 100
V OUT = 100mV P-P
LARGE-SIGNAL GAIN
vs. FREQUENCY
MAX9519 toc03
FREQUENCY (MHz)
NORMALIZED GAIN (dB)
10 1
-60
-50
-40
-30
-20
-10
0
10
-70
0.1 100
V OUT = 2V P-P
LARGE-SIGNAL GAIN FLATNESS
vs. FREQUENCY
MAX9519 toc04
FREQUENCY (MHz)
NORMALIZED GAIN (dB)
10 1
-7
-6
-5
-4
-3
-2
-1
0
1
2
-8
0.1 100
V OUT = 2V P-P
GROUP DELAY
vs. FREQUENCY
MAX9519 toc05
FREQUENCY (MHz)
DELAY (ns)
10 1
40
20
60
80
100
120
0
0.1 100
V OUT = 2V P-P
POWER-SUPPLY REJECTION RATIO
vs. FREQUENCY
MAX9519 toc06
FREQUENCY (MHz)
PSRR (dB)
10 1
-70
-60
-50
-40
-30
-20
-10
0
-80
0.1 100
V DD = 3.3V
V RIPPLE = 200mV P-P
QUIESCENT SUPPLY CURRENT
vs. TEMPERATURE
MAX9519 toc07
TEMPERATURE ( °C)
SUPPLY CURRENT (mA)
100 75 50 25 0 -25
2.5
2.6
2.7
2.8
2.9
2.4
-50 125
V IN = BLACK VIDEO SIGNAL
R L = 150 Ω
I SUPPLY = I DD - I OUT
VOLTAGE GAIN
vs. TEMPERATURE
MAX9519 toc08
TEMPERATURE ( °C)
VOLTAGE GAIN (V/V)
100 75 25 50 0 -25
3.96
3.97
3.98
3.99
4.00
4.01
4.02
4.03
4.04
4.05
3.95
-50 125
V IN = 600mV
V DD = 3.0V
OUTPUT VOLTAGE
vs. INPUT VOLTAGE
MAX9519 toc09
INPUT VOLTAGE (V)
OUTPUT VOLTAGE (V)
0.8 0.6 0.4 0.2
0.5
1.0
1.5
2.0
2.5
3.0
3.5
0
0 1.0
Typical Operating Characteristics
(V DD = 3.3V, GND = 0V, DC-coupled input, video output has R L = 150Ω connected to GND, T A = +25°C, unless otherwise noted.)
