Xerox Nuvera
®
100/120/144 EA Digital Production System - Customer Expectations Document
- 61 -
Dimensions BBF2005 BPRF BBF2005 Input Unit
Width x Depth x
Height
102” x 43” x 45”
2575 x 1095 x 1143 mm 64” x 31” x 51”
1625 x 787 x 1295 mm 30.5” (38” with bypass option) x
28.5” x 45”
775 x 725 x 1143 mm
Weight 1254 lbs (570 kg) 562 lbs (255 kg) 333 lbs (150 kg)
Weight - Shipping 1738 lbs (788 kg) 824 lbs (373 kg) 407 lbs (184 kg)
Clearance: Operator
Minimum 24” (610 mm) in front of
the device
Minimum 24” (610 mm) in front
of the device
Minimum 24” (610 mm) in front
of the device
Clearance: Service
Minimum 36” (914 mm) behind
the device Minimum 30” (763mm) on all
sides of the device Minimum 30” (763 mm) on all
sides of the device
Dimensions CMT-330 Cooling Tower Conveyors
Width x Depth x
Height
84" x 34.5” x 61”
2134 mm x 876 mm x 1549 mm 21.5” x 37” x 45.5”
550 mm x 950 mm x 116 mm In-feed: 40" x 29” x 26”
1020 mm x 740 mm x 660 mm
Exit: 47" x 12.2” x 39.5”
1200 mm x 310 mm x 1010 mm
Weight
2540 lbs (1140 kg) 335 lbs (152 kg) In-feed: 150 lbs (68 kg)
Exit: 85 lbs (39 kg)
Weight - Shipping 2850 lbs (1300 kg) 470 lbs (214 kg) 290 lbs (132 kg)
Clearance: Operator
Minimum 24” (610 mm) in front of
the device Minimum 24” (610 mm) in front
of the device
Minimum 24” (610 mm) in front
of the device
Clearance: Service
Minimum 30” (763 mm) on all
sides of the device
Minimum 30” (763 mm) on all
sides of the device
Minimum 30” (763 mm) on all
sides of the device
BPRF / BBF2005 / BBF Input Unit / CMT - 330
Electrical & Environmental
Minimum Maximum
Temperature Range 41 ° F (5° C) 85 ° F (29° C)
Humidity Range 50% RH 85% RH
Altitude -100 ft. (-31m) 4,000 ft. (1,219 m)
Heat Output
BPRF: 3240 btu/hr
BBF2005: 10024 btu/hr
CMT-330: 7500 btu/hr
Sound Emission
BPRF / BBF2005 / BBF 2005 Input: 79 db
CMT-330: 80db
BPRF
110 VAC, 60 Hz, 15A
230 VAC, 50 Hz, 10A
Power
BBF2005
220 VAC, 20A, 3 phase
380/400/415 VAC, 50 Hz, 20A
CMT-330 3 Phase, 60 Hz, AC 208/230 Volts, 25 Amps (service size 30 Amps)
Air CMT –330: 80 - 90 PSI, 5 CFM Un-lubricated
