Xerox Nuvera
®
100/120/144 EA Digital Production System - Customer Expectations Document
- 14 -
Product Space & Power Requirements
Item Xerox Nuvera
®
100/120/144 EA
Digital Production System
Comments
Size – Printer w/ 1 SFM
/ Scanner & MFF 132” (W) X 29 ” (D) X 61.6 ” (H)
3353 mm x 737 mm x 1565 mm
Size – Printer w/ 1 SFM
& SEM / FTM
125” (W) X 29 ” (D) X 61.6 ” (H)
3175 mm x 737 mm x 1565 mm
Printer Digital Tower 61.6” (1565 mm) (Height)
DFA finishing devices vary by device*.
Size – Printer w/ 1 SFM
& SEM / BFM
124” (W) X 29 ” (D) X 61.6 ” (H)
3150 mm x 737 mm x 1565 mm
Width of additional
SFM
31.7”, 805mm Optional
Width of BFM Plus 49”, 1233mm Optional, BFM Plus and Interface Module used with BFM (with top
tray) in dual BFM installations.
Service Space
(MFF Config.) Fixed: 163” (W) x 112” (D)
( 4140mm x 2839mm)
Moveable: 163” (W) x 92” (D)
( 4140mm x 2336.8mm)
- Fixed (stationary) installation: rear of the system should be at least
30” from the wall, machine, or rear obstruction..
- Moveable installation: rear of the system should be at least 10” from
the wall and must be on mobility plates OR hard surface floor AND
with no more than 4 modules including MFF and MFF Interface
Module.
Service Space
(BFM / FTM Config.
with SEM)
BFM: 145” (W) x 112” (D)
3683mm x 2839 mm
FTM: 143” (W) x 112” (D)
3632mm x 2839 mm
At least 30” from the wall in rear.
DFA finishing will increase width - FTM config. dimensions do not
include DFA Finisher(s) dimensions or service space.
Weight
(MFF Config. w/
scanner)
1,753 lb. (795.2 kg)
Additional SFM – 423 lbs. (192 kg) With consumables loaded, except media
Weight
(BFM / FTM Config.
with SEM)
BFM: 1763 lb. (800 kg)
FTM: 1713 lb. (777 kg)
Additional SFM – 423 lbs. (192 kg)
With consumables loaded, except media
FTM config. listing does not include DFA Finisher(s) weight.
Power Requirements
North America / Japan
(MFF / BFM Finishing)
187 – 240 Volts AC (Nominal), 50 Amp ,
50/60 Hz wall service
Note – FTM and DFA finishers will require
additional power
• UL & cUL compliant
• Complies with the FEMP (Federal Energy Management Program)
via the machine circuit breaker (CB); with the CB switched off, the
system consumes less than 1 watt.
• Energy Star (eStar) compliant**
• Environmental Choice (Canada)**
• Complies with Section 508 of the ADA Rehabilitation Act
Power Requirements
Europe / FX-IBG 187 – 240 Volts AC (Nominal), 30 Amp +
20 Amp (2) , 50/60 Hz wall service
Feeders and Finisher modules (BFMs) will
need additional 187 – 240 VAC (Nominal),
20 Amp, 50/60 Hz wall service
Note – FTM and DFA finishers will require
additional power
• Units are compliant with applicable EU directives and are CE
marked
* - Please refer to supported inline DFA finishing devices Solution Planning Guides for Product Space and
Power Requirements.
** - the following configuration is not Energy Star compliant:
• 100 ppm printer-only configuration with a BFM
