22 USSC
KEY PART # DESCRIPTION QTY.
1 69479 Feed Door Assembly 1
2 69497MB Louver Assembly 1
3 69498 Exhaust Duct Weldment 1
4 69499 Hopper Assembly 1
5 69477MB Top Weldment 1
6 69508MB Pedestal Bottom Weldment (6039) 1
7 25409MB Pedestal (6039) 1
8 25451MB Pedestal Back (6039) 1
9 69503MB Lid Weldment 1
10 69478MB Ash Pan Weldment (6039) 1
11 25493 Corner, Trim (6039) 1
12 25468MB Pedestal Trim, Front (6039) 1
13 25471MB Pedestal Trim, Right (6039) 1
14 25472MB Pedestal Trim, Left (6039) 1
15 891125 Latch, Hopper Lid 1
16 86619 Burnpot 1
17 69486MB Left Side Weldment 1
18 80486B Circuit Board 1
19 891054 Auger 1
20 80472 Blower, Distribution 1
21 80473 Blower, Exhaust 1
22 80456 Auger Motor 1
23 25412MB Cabinet Side, Right 1
24 25413MB Cabinet Back 1
25 891139 Ceramic Brick 1
26 83511 Washer, Rubber 1
27 25080MB Latch, Door 1
28 88106 Gasket, Distribution Blower 1
29 88100 Gasket, Exhaust Blower 1
30 80462 Recepticle, 3 Prong 1
31 891136 Coupling, Shaft 1
32 83533 Roll Pin, 1/8” dia X 7/8” 1
33 88114 Gasket, Exhaust Duct 1
34 80381 Low Limit Switch (F110 Thermodisc- 60T12) 1
35 80455 Auger Safety Switch (F250 Thermodisc- 60T11) 1
36 80478 Switch, Pressure 1
37 25443 Bracket, Pressure Switch 1
38 25447 Support Frame (Back/Right) 1
39 25448 Support Frame (Back/Left) 1
40 80461 Power Supply Cord 1
41 88116 Insulation, Blanket 1
42 891138 Handle, Brass 1
43 891059 Agitator 1
44 25427 Retainer, Agitator Motor 1
45 83529 Hairpin 1
46 83901 Roll Pin 1
47 891132 Bushing, Agitator 1
48 25422 Bracket, Agitator/Bushing 1
49 80457 Motor, Agitator 1
50 83534 Ring, Retaining 1
51 88111 Gasket, Agitator Bracket 1
52 86620 Shaft, Agitator Drive 1
53 89586 Nipple, Auger 1
54 891121 Hose, Blue Silicone 5 Inches
55 25456MB Cover, Ash Dump 2
REPAIR PARTS LIST-6039
N/S = NOT SHOWN
FOR MODEL: 6039
