Chapter 3 I/O Information
NI PXI-8183 User Manual 3-6 ni.com
Parallel Port
Figure 3-5 shows the location and pinouts for the IEEE 1284 (parallel)
connector on the NI PXI-8183. Table 3-5 lists and describes the IEEE 1284
connector signals.
Parallel port adapter cables are available from National Instruments,
part number 777169-01.
Figure 3-5. Parallel Port Connector Location and Pinout
5 NC
6 Differential Receive
7 NC
8 NC
Table 3-4. Ethernet Connector Signals (Continued)
Pin Signal Description
Parallel Port
36
19
18
1
NI PXI-8183
Embedded Controller
