© National Instruments Corporation 3-1 NI PXI-8183 User Manual
3
I/O Information
Front Panel Connectors
Table 3-1 lists various peripherals and their corresponding NI PXI-8183
external connectors, bus interfaces, and functions.
Table 3-1. NI PXI-8183 Peripherals Overview
Peripheral
External
Connector Function
Video 15-pin D-SUB
(standard VGA) Integrated with Dynamic Video Memory
Serial COM1 RS-232 Serial
Port (9-pin D-SUB) 16550 serial port
10/100 Ethernet Ethernet Ethernet network connection
Parallel Parallel Port
(IEEE 1284) Extended capabilities
USB 4-pin Series A
receptacle Universal Serial Bus
(two ports on all models)
Keyboard/mouse PS/2 PS/2-style keyboard and mouse
(mouse requires PS/2 Y splitter)
PXI trigger Trigger Routing PXI triggers to or from the backplane
trigger bus
