Chapter 3 I/O Information
NI PXI-8183 User Manual 3-2 ni.com
Front Panel
Figure 3-1 shows the front panel layout and dimensions of the
NI PXI-8183. Dimensions are in inches [millimeters].
Figure 3-1. NI PXI-8183 Front Panel Layout and Dimensions
NI PXI-8183
Embedded Controller
.68 [17.1]
1.25 [31.8]
1.52 [38.5]
1.85 [47.1]
2.49 [63.3]
3.00 [76.3]
3.46 [87.9]
1.20 [30.4] 0.95 [24.2] 0.
8
6 [21.9]
0.34 [
8
.7]
.00 [0]
0.97 [24.6] 0.94 [23.9]
0.34 [
8
.7]
.00 [0]
