Normal Dial Tone:
The dial tone parameters are defined by six fields: Freq1, Freq2, OnTime1, OffTime1,
OnTime2, and OffTime2.
RingBack tone:
The ring back tone parameters are defined by six fields: Freq1, Freq2, OnTime1,
OffTime1, OnTime2, and OffTime2.
Alerting Tone:
The alerting tone parameters are defined by six fields: Freq1, Freq2, OnTime1, OffTime1,
OnTime2, and OffTime2.
Recall Tone:
The recall tone parameters are defined by five fields: Freq1, Freq2, OnTime1, OffTime1
and Duration.
Busy Tone:
The busy tone parameters are defined by six fields: Freq1, Freq2, OnTime1, OffTime1,
OnTime2, and OffTime2.
Call waiting Tone:
The call waiting tone parameters are defined by six fields: Freq1, Freq2, OnTime1,
OffTime1, OnTime2, and OffTime2.
Congestion Tone:
The congestion tone parameters are defined by six fields: Freq1, Freq2, OnTime1,
OffTime1, OnTime2, and OffTime2.
Stutter Dial Tone:
The stutter dial tone parameters are defined by five fields: Freq1, Freq2, OnTime1,
OffTime1 and Duration.
VMI Dial Tone:
The stutter dial tone parameters are defined by five fields: Freq1, Freq2, OnTime1,
OffTime1 and stutter Duration. This plays a distinctive stutter dial tone on Off Hook when
there are Voice Mails waiting on the phone.
Ring Tone Action:
The VOIP ATA provides a drop-down option (Display, Add, or Edit or Delete) for the user
to manipulate the ring-tone parameters for the working country. Ring-tone parameters for a
country can be displayed, added, and edited.
• Display: This is the default option. Selection of this option will display the selected
country in the Working Country field after clicking on the Submit button.
• Add: Selection of the Add option adds a new country after clicking on the Submit
button according to the value that appears in the Working Country field. This field
must not be empty.
