Chapter 3 - Installing Your VOIP ATA
3.1 Typical VOIP ATA Connection
You need to have a ADSL modem or Cable modem before you can connect to the VOIP ATA. It
can be placed behind router or straight from the modem. Check if your Computer/Notebook has an
Ethernet Port. The Telephone set is connected to the RJ-11
3.1.1
ADSL Connection Diagram
Figure 3-1 below shows a ADSL Modem+Router connection diagram.
Figure 3-1: Connection via ADSL Modem+Router
