Introduction
1-5
Quick Components Guide
Component Function Reference
DIMM1~2 Installing DIMM modules See p. 2-5~2-6
Socket 478 Installing CPU See p. 2-2~2-4
C_FAN1 Connecting to CPU FAN See p. 2-22
S_FAN1 Connecting to SYSTEM FAN See p. 2-22
ATX Power Supply Installing power supply See p. 2-7
JPW1 Connecting to 12V ATX power supply See p. 2-8
IDE1& IDE2 Connecting to IDE hard disk drives See p. 2-14
FDD1 Connecting to floppy disk drive See p. 2-13
USB1/2 Connecting to USB interfaces See p. 2-24
PCI Slot 1~3 Installing PCI expansion cards See p. 2-27
AGP Slot Installing AGP cards See p. 2-27
CNR Slot Installing CNR cards See p. 2-27
JMDM1 (Optional) Connecting to modem module See p. 2-20
JWOL1 Connecting to LAN module See p. 2-19
JBAT1 Clearing CMOS data See p. 2-26
F_P1/2 Connecting to case See p. 2-15
JGS1 Connecting to power saving switch See p. 2-19
IR1/2 Connecting to IR modules See p. 2-21
JAUDIO1 Connecting to front audio connectors See p. 2-25
