LSI20160 Single Channel Ultra160 SCSI to PCI Host Adapter vii
Copyright © 2001 by LSI Logic Corporation. All rights reserved.
Contents
Chapter 1 Describing the LSI20160
1.1 General Description 1-1
1.2 Features 1-2
1.2.1 PCI Interface 1-2
1.2.2 SCSI Interface 1-3
1.2.3 Board Characteristics 1-4
1.2.4 SCSI Activity LED Interface 1-4
1.3 Ultra160 SCSI Benefits 1-4
1.3.1 Double Transition (DT) Clocking 1-4
1.3.2 Cyclic Redundancy Check (CRC) 1-5
1.3.3 Asynchronous Information Protection (AIP) 1-5
1.4 SureLINK™ Ultra160 SCSI Domain Validation Benefits 1-5
1.5 LVDlink™ Technology Benefits 1-5
1.6 TolerANT
®
Technology Benefits 1-6
Chapter 2 Installing the LSI20160
2.1 Quick Installation Procedure 2-1
2.2 Detailed Installation Procedure 2-2
2.2.1 Before You Start 2-2
2.2.2 Selecting a PCI Slot 2-3
2.2.3 Inserting the Host Adapter 2-4
2.2.4 Connecting SCSI Peripherals 2-6
2.2.5 SCSI Bus Termination 2-15
2.2.6 Setting SCSI IDs 2-18
2.3 Completing the Installation 2-20
Chapter 3 Technical Specifications
3.1 Physical Environment 3-1
3.1.1 Physical Characteristics 3-1
