Detailed Installation Procedure
2-5
Copyright © 2001 by LSI Logic Corporation. All rights reserved.
Step 3.
Secure the bracket with the bracket screw before making the
internal and external SCSI bus connections.
shows
an example on how to insert your host adapter.
Figure 2.2
Inserting the Host Adapter
Bracket Screw
32-bit Slots
64-bit Slots
