Ultra320 SCSI to PCI-X Host Adapters vii
Copyright © 2002 by LSI Logic Corporation. All rights reserved.
Contents
Chapter 1 Quick Installation Procedures
1.1 General Description 1-1
1.2 Quick Host Adapter Installation 1-2
1.3 Quick Windows Driver Installation 1-4
Chapter 2 Detailed Host Adapter Installation
2.1 Installing your Ultra320 SCSI Host Adapter 2-1
2.1.1 Selecting a PCI Slot 2-1
2.1.2 Inserting the Host Adapter 2-3
2.2 SCSI Device Cables 2-4
2.2.1 Internal SCSI Cables 2-4
2.2.2 External SCSI Cable 2-5
2.3 Connecting SCSI Devices 2-6
2.3.1 Connecting Internal SCSI Devices 2-6
2.3.2 Connecting the LED Cable 2-8
2.3.3 Connecting External SCSI Devices 2-9
2.4 Terminating the SCSI Bus 2-11
2.4.1 LSI20320 Host Adapter Termination 2-11
2.4.2 LSI21320 Host Adapter Termination 2-11
2.4.3 LSI22320 Host Adapter Termination 2-11
2.5 Setting SCSI IDs 2-12
2.6 Completing the Installation 2-13
Chapter 3 Ultra320 SCSI Host Adapter Board Characteristics
3.1 Ultra320 SCSI to PCI-X Host Adapters 3-1
3.1.1 LSI20320 Single Channel Host Adapters 3-2
3.1.2 LSI21320 Dual Channel Host Adapters 3-4
3.1.3 LSI22320 Dual Channel Host Adapters 3-6
3.2 Host Adapter Characteristics 3-8
