Page 37
Ultra320 SCSI to PCI-X Host Adapters
3-7
Rev. 2.0
Copyright © 2002 by LSI Logic Corporation. All rights reserved.
Figure 3.4
LSI22320 and LSI22320-R Drawing
J1 PCI and PCI-X
Channel B
Channel A
J5
J6
J3
LSI53C1030
J4
Ultra320 SCSI LVD/SE
J2
Ultra320 SCSI LVD/SE
Channel A - Ultra320 SCSI LVD/SE
Channel B - Ultra320 SCSI LVD/SE
