Figure 3.3
LSI21320 or LSI21320-R Drawing
J1 - PCI and PCI-X
LSI53C1030
J2
Channel A
Ultra320 SCSI LVD/SE
J3
Channel B
Ultra320 SCSI LVD/SE
J6 for
Channels
A and B
J4
Channel A
Ultra320 SCSI LVD/SE
