Link electronic GT701AP User Manual
Page 43
42
6.
In the General tab, activate “Use the following IP address” by clicking on the
circle. When active, a black dot will appear in the circle. If the circle already
contains a black dot, leave it alone.
7.
Enter the following numbers in the “IP Address” text box:
192.182.0.2
Don't include the periods; they are automatically entered.
8.
Enter the following numbers in the “Subnet mask” text box:
255.255.255.0
9.
Click OK. The Internet Protocol (TCP/IP) Properties window disappears.
10. In the Local Area Connection Properties window, click OK. The Local Area
Connection Properties window disappears.
11. Click Close in the Local Area Connection Status window. The window disap-
pears.
12. Close the Network and Dial-up Connections window by clicking on the “x”
button at the upper right corner of the window. The IP address on the com-
puter is changed.
