MODE ADJUST
Selecting MODE ADJUST on the MAIN
MENU accesses the MODE ADJUST menu,
which appears highlighting the name of the
active listening mode. Use the up and down
MENU arrows to scroll through the
complete list of listening modes. Press the
right MENU arrow to select the highlighted
listening mode for configuration. Press the
left MENU arrow to return to the MAIN
MENU.
All listening modes can be selected from the
MODE ADJUST menu. Selecting the desired
listening mode accesses a menu containing
specific options and parameters that can be
adjusted to customize the selected mode.
These menus are pictured on pages A-10
and A-11. Other methods of listening mode
selection are reviewed on pages 2-17 and
2-18.
LISTENING MODE DESCRIPTIONS
LOGIC7 FILM
• A proprietary Lexicon listening mode.
• Designed for playback of 2-channel stereo or matrix encoded
stereo film sources.
L7 FILM
• Derives seven channels from 2-channel input types.
• Derives full-frequency stereo surrounds, realistically increasing
the perceived width of the listening space. With side and rear
speakers selected, LOGIC7 FILM also increases the perceived
length and sense of envelopment of the listening space.
• Provides remarkable improvement compared to other
decoders.
• Recommended for 2-channel film sources, even when only one
pair of surround speakers is selected.
Default
Parameter Value Values
AUTO AZIMUTH ON ON, OFF
VOCAL ENHANCE +0.0dB +0.0dB, +3.0dB, +6.0dB
RE-EQUALIZER ON ON, OFF
SOUND STAGE REAR FRONT, NEUTRAL, REAR
5 SPKR ENHANCE OFF ON, OFF
BASS ENHANCE OFF ON, OFF
SURR ROLLOFF 15.3kHz 500Hz to 20.0kHz, OFF
REAR DLY OFFSET 15ms 0 to 30ms
OUTPUT LEVELS See page 5-17 for more information
CUSTOM See page 5-17 for more information
An alphabetical listing of parameter descriptions begins on page 5-20.
5-2
The MODE ADJUST Menu
JBL
MODE ADJUST
MODE ADJUST
FILM
TV
MUSIC
PL II
PRO LOGIC II
PL II MUSIC
PRO LOGIC
2-CHANNEL
PARTY
MONO
MONO LOGIC
MONO SURROUND
5.1 FILM
5.1 TV
5.1 MUSIC
5.1 SUR EX
DIGITAL
5.1 2-CHANNEL
5.1 MONO
5.1 MONO LOGIC
5.1 MONO SURR
FILM
MUSIC
2-CHAN
5.1 BYPASS
2CH BYPASS
