Document version 1.0 Page 5 9/1/2004
Single monitor configurations.
1. Single monitor, single-link DVI (13Hz)
Single-link DVI
T221 (9503-DG3/5)
3840x2400@13Hz
NVIDIA Quadro4 980XGL
NVIDIA Quadro FX1000
NVIDIA Quadro FX3000
IntelliStation M/Z-Pro
Single-link DVI
not connected
Driver level
As per minimum level
Graphics cards As per supported list
T221 EDID
029 (default)
Update rate 13Hz
Desktop Single
2. Single monitor, twin single-link DVI (20Hz)
Single-link DVI
T221 (9503-DG3/5)
3840x2400@20Hz
NVIDIA Quadro4 980XGL
NVIDIA Quadro FX1000
NVIDIA Quadro FX3000
IntelliStation M/Z-Pro
Single-link DVI
Driver level
As per minimum level
Graphics cards As per supported list
T221 EDID
029 (default)
Update rate 20Hz
Desktop Single (horizontal span via NVIEW utility)
Dual view (extend desktop via OS)
