Document version 1.0 Page 4 9/1/2004
T221 Model 9503-DG3 9503-DG5
Inputs Single-link DVI (each, max 4)
- 165MHz pixel clock limit
- 495MB/sec (24bit RGB) Single-link DVI (each, max 4)
- 165MHz pixel clock limit
- 495MB/sec (24bit RGB)
Dual-link DVI (1x), via converter box
- 330MHz pixel clock limit
- 990MB/sec (24bit RGB)
Internal panel
refresh rate 41Hz 41-48Hz
Main high resolution
modes
(recommended) 1x DVI input = 3840x2400@13Hz
2x DVI input = 3840x2400@20Hz
4x DVI input = 3840x2400@41Hz Dual-link DVI modes
1x DVI input = 3840x2400@24Hz
Single-link DVI modes
1x DVI input = 3840x2400@13Hz
2x DVI input = 3840x2400@20Hz
2x DVI input = 3840x2400@24Hz
4x DVI input = 3840x2400@48Hz
