INSTALL FACE PLATE AND HANDLE
9.
Remove and discard the plaster
guard, if installed.
Rotate the valve stem fully
counterclockwise.
Install the handle and face plate
onto the valve and carefully
secure with screws. Do not
overtighten the screws.
Face Plate
Screws
Valve Stem
Plaster Guard w/Dome
Discard
