6 GB/IE
Car Radio KH 2380
L Introduction
L For your personal safety
Please read the operating instructions carefully; to
do so, unfold the pages featuring the illustrations.
Pay precise attention to the notes when taking the
device into operation. Should you have any further
questions on how to use this car radio recorder,
please contact your national service point (see
guarantee card). Store the operating instructions
safely for later reference and hand them to third
parties when passing your car radio recorder to a
new user.
L Proper Use
The KH 2380 car radio is suitable for private use for
receiving radio stations in the FM / MW / LW range and
for playing back CD, CD-R, CD-RW, USB Memory-
Stick, MP3 Player, SD and MMC audio storage media.
It is able to make recordings in WMA format on to
SD, MMC or USB memory stick (not supplied) of the
radio stations being played back. The car radio has
a removable control panel and an IR remote control
device which can only be supplied with electricity by
means of 1 lithium battery of type CR202, 3 V DC.
The car radio may only be connected to the 12 V
DC supply. The device is suitable for connecting to
four loudspeakers with an impedance of 4-8 Ohm,
a maximum of four power amplifiers (to the four
speaker output channels) and a CD changer.
Any careless use or use other than for the intended
purpose will result in the guarantee becoming invalid.
L Equipment
Front of the Control Panel (Fig. A)
1 Control panel
2 Plastic frame
3 Display window
4 “Open” button
5
:
“Skip” button (forwards)
6
9
“Skip” button (reverse)
7 AF “AF” button
8 TA “TA” button
9 PTY “PTY” button
bl 6 “6” button
bm 5 “” button
bn 4 RDM “4 / RDM” button
bo 3 INT “3 / INT” button
bp 2 RPT “2 / RPT” button
bq 1 PAU “1 / PAU” button
br DISP “DISP” button
bs
BD / ENT “BD/ENT” button
bt SCAN REC• “SCAN / REC” button
bu
• LD / MD “LD / MD” button
cl MU “MU” button
cm A / PS “A / PS” button
cn
PWR / DIM
“PWR / DIM” button
co Sensor (remote control)
cp “SEL / VOL” control knob
Reverse of the Control Panel (see Fig. B)
cq Unlock mechanism 2 x
cr Plug-in connection strip
Front of the Car Radio
(Control Panel removed) (see Fig. C)
cs LED (red) / CD compartment
ct Front
cu CD compartment
dl Connection socket
dm Opening mechanism
dn SD and MMC port
do USB port
dp Control panel attachment point 2 x
dq LED (red) / power supply
dr Reset button
ds CD eject button
Introduction
