11 GB/IE
i TA / TP (Traffic Announcement/Traffic
Program): Function to receive traffic updates.
i EON (Enhanced Other Networks): If TA / TP
function is activated, while listening to a
broadcasting of a radio station the programme
switches automatically as soon as traffic updates
are broadcast. Traffic updates are then
broadcast at a pre-set volume.
i PTY (Program Type): Function to receive
special program (e.g. rock music).
i HiFi (High Fidelity): Quality standard for audio
replay devices.
i DIN 8 pole plug: adapter to connect electronic
HiFi device in accordance with DIN standard (e.
g. CD changer connection to a MP3 car radio
recorder).
i ISO plug: Adapter to connect electronic HiFi
devices in accordance with International
Organization for Standardization.
L Preparation
The following auxiliaries and tools are required for
the connection and for the assembly, which are not
included in the delivery:
1 x ISO plug to connect car’s loudspeaker
1 x ISO plug to make 12 V DC connection
1 x Powered aerial connection with connector
1 x Pair of loudspeakers impedance 4 - 8 Ohm,
(incl. feed line)
3 x Fuse holder with fuse 1 A
1 x DIN assembly cut-out in car’s instrument panel
9 x Biscuit connectors
1 x Stripping tongs or cable stripping knife
1 x Screw driver
1 x Spanner with 8 mm opening
1 x Biro
To connect an antenna already installed in the
vehicle you may need:
1 x Antenna adapter (in accordance with the
Technical Data for the antenna)
To connect a CD changer you require:
1 x Connecting line with DIN-8-pole plug
To connect a final amplifier you require:
2 x Cinch connecting cable
(insulation and plug: white / red)
For the connection of a portable audio device
you require:
1 x Cinch connection cable / 3. mm jack
(insulation and plug: white / red)
To record MP3 or WMA formats you require:
1 x MMC approx. 1 GB storage capacity
or
1 x SD approx. 1 GB storage capacity
or
1 x USB memory stick approx. 1 GB storage
capacity
L
Installation
L Removing the control panel
from the car radio
• Avoid hard contact with the display window 3 .
• Press the “Open” button 4 and allow the
control panel 1 to reach the horizontal
position.
• Push the control panel 1 slightly to the left and
pull it forwards.
• Store the control panel in the plastic box (see
also the illustration in the section “Attaching
the Control Panel”).
L Installation of the DIN assembly
bracket into the car’s instrument
panel
• Completely unscrew the safety transport
screws gp from the metal casing dt (see Fig. E)
and carefully remove the plastic frame 2
from the front of the device ct .
• Release the attachment points by slightly
raising the upper frame edge and pulling it
carefully towards the front.
• Push the two installation keys between the
Safety / Preparation / Installation
