FAQs
Insignia 32” LCD HDTV 720p (NS-LCD32-09)
September 30, 2008
My picture is not filling the screen. I have black bars around my picture.
• This is due to the aspect ratio. An increasing amount of digital TV programming and movies are presented in wide
screen (16:9).
• To change the appearance of the screen, cycle through these four options by pressing the Zoom button on the remote:
o Normal: Selects the aspect ratio that matches to source’s aspect ratio (4:3 or 16:9)
o Wide: Displays a full-screen image
o Zoom: Enlarges the picture. The top and bottom may be cropped.
o Cinema: Stretches the image at the edges while maintaining a clear image in the center of the screen.
How do I hook up my external device (e.g., game system, DVD player, VCR, etc.)?
• What type of cable are you using?
o HDMI
ƒ Connect an HDMI cable to the HDMI 1 or HDMI 2 jack on the back of your TV or HDMI 3 jack on the
side of your TV and to the HDMI Out jack on the HDMI device.
ƒ To play from an HDMI device:
• Turn on the HDMI device, then set it to the correct mode. See the documentation that came
with the device for further instructions.
• Turn on your TV, then press INPUT. The Source List menu opens.
• Press
^ or v to select HDMI 1, HDMI 2, or HDMI 3, then press ENTER.
o Component Video Cables are red, green and blue. The audio cables will be red and white.
ƒ Connect a component cable to the COMPONENT 1 or COMPONENT 2 jacks on the back of your TV
and to the COMPONENT Out jacks on the component device.
ƒ To play from a component device:
• Turn on the component device, then set it to the correct mode. See the documentation that
came with the device for further instructions.
• Turn on your TV, then press INPUT. The Source List menu opens.
• Press
^ or v to select Component 1 or Component 2, then press ENTER.
o S-Video Cable has a round end with prongs in a semi-circle and Audio Cables that are red and white.
ƒ Connect an S-Video cable to the S-VIDEO REAR jack on the back of your TV or S-VIDEO SIDE jack
on the side of your TV and to the S-VIDEO Out jack on the S-Video device.
ƒ Connect an audio cable to the L AV 1 IN and R AV 1 IN jacks on the back of your TV or L AV 2 IN and
R AV 2 IN and to the Audio Out jacks on the S-Video Device.
ƒ To play from an S-Video device:
• Turn on the S-Video device, then set it to the correct mode. See the documentation that came
with the device for further instructions.
• Turn on your TV, then press INPUT. The Source List menu opens.
• Press
^ or v to select S-VIDEO REAR or S-VIDEO SIDE, then press ENTER.
o Composite (A/V Cables, RCA Cables) have a yellow video cable, and red and white audio cables.
ƒ Connect a composite cable to the AV 1 IN jacks on the back of your TV or AV 2 IN jacks on the side of
your TV and to the Video Out and Audio Out jacks on the composite device.
ƒ To play from a composite device:
• Turn on the Composite device, then set it to the correct mode. See the documentation that
came with the device for further instructions.
• Turn on your TV, then press INPUT. The Source List menu opens.
• Press
^ or v to select Composite Rear or Composite Side, then press ENTER.
