Maintenance
—
Chapter 3
31
PK80 Series 80-Column User’s Manual
5
Close the paper bail, reinsert the print head, latch the two print head
locking tabs, and install the ribbon.
1 Print head locking tabs
2 Print head (lifted aside)
3 Mask spring
4 Paper bail (raised)
1
2
3
4
