Old Ribbon Cartridge Removal
Physically move the print head mechanism to an open area, then do the
following to remove the old ribbon cartridge:
1
Squeeze the ribbon cartridge locking tab (on the side of the cartridge)
against the ribbon cartridge.
2
Lift the ribbon cartridge to remove the ribbon from the print head. En-
sure the ribbon does not catch.
3
Lift the ribbon cartridge out of the printer.
Locking Tab
