OnLine Power
(6002-1646) REV.X8 33
POWER RATING (KVA/KW) 3.0
5.0
7.5
10
12.5 15
BATTERY
BATTERY RUN TIME See Appendix C for various Run time
BATTERY TYPE Sealed, Maintenance-Free, AGM, VRLA type
NOMINAL DC VOLTAGE 96 VDC 120 VDC 120 VDC 192 VDC 192 VDC 240 VDC
OVERCURRENT PROTECTION Circuit Breaker
PACKAGING Batteries Housed in Same Enclosure and/or additional battery cabinet (See Table 2-1)
MONITORING AND COMMUNICATIONS
LCD SCREEN Input Voltage, Batt. Charger, UPS Output; On Batt.; Low Batt.; Summary Alarm
INDICATORS LCD Display Panel
RELAY INTERFACE Dry Contacts for:
UPS On (N.C.); On Inverter (N.O.); Loss of Input Power (N.O.); Low Battery (N.O.)
CONTACT RATING 125 Volts (AC or DC) Maximum; 1.25 Amperes Maximum; 30 Watts / 50 VA Maximum
INTERFACE CONNECTION Hard Wired (Terminal Block)
ENVIRONMENTAL
USRGE WITHSTANDABILITY ANSI C62.41-1980 Categories A & B
OPERATING TEMPERATURE Meets NEMA Requirements
OPERATING RELATIVE HUMIDITY 0 to 95% Non-Condensing
ALTITUDE Up to 6,000 Feet (1,829 Meters) with No De-Rating
COOLING Air Cooled-Forced Fan
PHYSICAL
SIZE WxHxD in. (cm) 18 x 35 x 32 (45.7 x 88.9 x 84.3 cm)
WEIGHT ibs (kg) with batteries 600(273) 900(409) 1150(523) 1600(727) 1850(841) 2250(1023)
CONSTRUCTION Painted Steel Enclosure with 3 Point Double Locking Front Door; and Full-Length Door Hinge.
ENCLOSURE Designed for Inside Installations
COLOR Natural finish
ACCESSIBILITY Front - All Servicing is Through the Front; No Side or Rear Access is Required.
CABLE ENTRY Bottom or sides
MOUNTING Four (4) Holes Provided to Anchor Enclosure to Pedestal (Supplied by Others)
