(6002-1646) REV.X8 32
APPENDIX D: SPECIFICATION
POWER RATING (KW) 3.0 5.0 7.5 10 12.5 15
VOLTAGE (VAC) INPUT
Single Phase,
120/208/240
Single Phase, 240/208VAC
MAXIMUM CURRENT 40/19/16 58/30/28 41/36 58/50 69/60 83/72
TOLERANCE +10% to -15%
FREQUENCY (Hz) 60 +/- 3%
POWER FACTOR 0.98 to 1.0 (Typical)
OVERCURRENT PROTECTION Electronic / Circuit Breaker
NUMBER OF WIRES 2 Wires plus Ground
POWER CONNECTION Hard Wired (Terminal Block)
OUTPUT
RATING (KVA/KW)
3.0 5.0 7.5 10 12.5 15
VOLTAGE (VAC) 120/120/240 120/120/240 120/240 120/240 120/240 120/240
VOLTAGE REGULATION +/-3% No Load to Full Load; +/-3% High Line to Low Line
FREQUENCY (Hz) 60 Hz +/-0.25 Hz (When on Inverter)
WAVESHAPE Sine Wave
HARMONIC DISTORTION <5% THD; <3% Single Harmonic
CREST FACTOR Up to 3 to 1
POWER FACTOR 1.0PF
STEADY-STATE CURRENT 25/12.5 42/20.8 62.5/31.3 83.3/41.7 104/52 125/62.5
OVERLOAD 125 % for One (1) minutes, surge 150 %
PROTECTION Electronic / Circuit Breaker
NOISE REJECTION -120 kB Common Mode; -60 kB Normal Mode
NUMBER OF WIRES 2 Wires plus Ground
POWER CONNECTION Hard Wired (Terminal Block)
