UL1481 MICRO-CHIPS & OTHER COMPONENT’S LIST
MODEL
NUMBER
INPUT
KW /
KVA
OUTPUT
VOLTAGE
MICRO-CHIP
SOFTWARE
BASIC UPS KIT LABEL KIT
INPUT
CONTACTOR
BATT
C.B.
FANS
1 WR3.0A58FPT1 120 120/240V 9100-1319-018UL 9100-1312-11 9100-1295-02 1680-242 2025-769 1000-036
2 WR3.0B58FPT1 208 120/240V 9100-1319-023UL
3 WR3.0D58FPT1 240 120/240V 9100-1319-025UL 9100-1312-11 ‘’ " " ‘’
5 WR5.0A58FPT1 120 120/240 9100-1319-050UL 9100-1312-11 ‘’ 1680-093 2025-768 ‘’
6 WR5.0B58FPT1 208 120V/240 9100-1319-055UL 9100-1312-11 " " "
7 WR5.0D58FPT1 240 120/240 9100-1319-057UL 9100-1312-11 " " ‘’ ‘’
9 WR7.5B58FPT1 208 120/240 9100-1319-77UL 9100-1312-11 ‘’ 1680-093 2025-759 ‘’
10 WR7.5D58FPT1 240 120/240V 9100-1319-081UL 9100-1312-11 " "
11 ‘’ ‘’ ‘’ ‘’
12 WR010B58FPT1 208 120/240V 9100-1319-101UL 9100-1312-11 " 1680-139 2025-772
13 WR010D58FPT1 240 120/240 9100-1319-105UL 9100-1312-11 ‘’ ‘’ ‘’ ‘’
14
15 WR012B58FPT1 208 120/240 9100-1319-125UL 9100-1312-11 ' 1680-187 2025-759
16 WR012D58FPT1 240 120/240 9100-1319-129UL 9100-1312-11 " " "
17
18 WR015B58FPT1 208 120/240 9100-1319-149UL 9100-1312-11 ‘’ ‘’ "
19 WR015D58FPT1 240 120/240V 9100-1319-153UL 9100-1312-11 " ‘’ ‘’ ‘’
20
21 WR3.0401FPN1 120 120 9100-1319-017UL 9100-1312-10 ‘’ 1680-242 2025-769 ‘’
25 WR5.0A01FPN1 120 120 9100-1319-049UL 9100-1312-10 1680-093 2025-768
MODEL PART NUMBER NOMENCLATURE
WR 3.0 A 01 FP N 1 -XXX
Basic Model
#
KVA Rating
Input Voltage
AC
A=120V
B=208V
Output Voltage
01=120V
58=120V 120/240V
Example of prime
t
Reserve for
designated option or
Single Phase
Output XFMN
N=No output
XFMN
Designate
( Fire Protective UPS)
