32

Insignia NS-H3005 Home Theater System

www.insignia-products.com

Moisture condensation

Moisture condensation can occur:

When the home theater system is moved
from a cold place to a warm place.

Under extremely humid conditions.

In locations where moisture condensation may
occur:

Keep the home theater system plugged into
an AC power outlet with POWER On. This
will help prevent condensation.

When condensation has occurred, wait a few
hours for the home theater system to dry
before using it.

Specifications

Design and specifications are subject to change
without prior notice.

indicator

appears after
home theater
system is turned
off.

home theater system
is in Timer Recording
mode.

This is the normal
indication that the
home theater system
is in TIMER mode.

Stereo Audio
Record and/or
Playback is not
present.

Television is not
Stereo-compatible.

No action is possible.

Broadcast program is
not in stereo format.

No action is possible.

Home theater system
BROADCAST TYPE
mode is set to SAP or
MONO.

Set BROADCAST TYPE
to STEREO. See
“Setting up the VCR”
on page 11.

General

Power requirements

AC 120V, 60 Hz

Power consumption

50 W

Dimensions (approx.)

16.9 x 3.5 x 13.8 inches
(430 x 90 x 350 mm)

Weight (approx.)

17.6 lbs (8 kg)

Operating temperature

41°F to 95°F (5°C to 35°C)

Operating humidity

5% to 90%

Signal system

NTSC

Inputs

ANTENNA IN

Antenna or CATV input, 75 ohms

VHS VIDEO IN(LINE1, 2) 1 Vp-p 75 ohms sync negative, RCA jack

x 2

VHS AUDIO IN(LINE1, 2) -6.0 dBm more than 47 ohms, RCA jack

(L, R) x 2

Outputs

MONITOR OUT

1 Vp-p 75 ohms, sync negative

Component Video output (Y) 1.0 V (p-p), 75 Ù negative sync RCA

jack x 1 (Pb)/(Pr) 0.7 V (p-p) 75 Ù, RCA
jack x 1

VCR

Head system

Four head helical scan azimuth system

Timer

12-hour display type with AM, PM

Tape speed

SP: 33.35 mm/sec
LP: 16.67 mm/sec
SLP: 11.12 mm/sec

Symptom

Cause

Correction

Tape width

12.7 mm

Maximum recording
time

SP: 2 hours (T-120)
SLP: 6 hours (T-120)
SLP: 8 hours (T-160)

Rewind time

About 3 minutes (T-120)

Antenna

75 ohms (VHF/UHF)

VHF output signal

Channel 3 or 4

Channel coverage

VHF: 2-13
UHF: 14-69
CATV: 1-125 (4A, A-W, W+1 - W+84,
A-5 - A-1)

Frequency range

200Hz to 8kHz

Signal-to-noise ratio

More than 65 dB (EE mode)

Dynamic range

More than 70 dB (EE mode)

Channel separation

More than 45 dB (EE mode)

DVD

Laser system

Semiconductor laser wavelength 650
nm

Frequency response

DVD (PCM 96 kHz): 20 Hz to 44 kHz
DVD (PCM 48 kHz): 20 Hz to 22 kHz
CD: 20 Hz to 18 kHz

Signal-to-noise ratio

More than 70 dB

Harmonic distortion

Less than 0.5%

Dynamic range

More than 65 dB (DVD/CD)

Tuner

System

PLL quartz-locked digital synthesizer
system

Tuning range

87.5 - 108.0 MHz (FM)
530 - 1720 KHz (AM)

Antenna

Wire antenna (FM)
Loop antenna (AM)

Satellite (LHS-36SCS) Speakers

Type

1 Way Speakers

Impedance

4 ohm

Frequency Response

140 - 20,000 Hz

Sound Pressure Level

85 dB/W (1m)

Rated Input Power

45W

Max Input Power

90W

Net Dimensions

3.6 x 4.5 x 3.1 inches
(92 x 115 x 80 mm)

Net Weight

1.1 lbs (0.5 kg)

Passive Subwoofer (LHS-36SCW)

Type

1 Way Speaker

Impedance

8 ohm

Frequency Response

60 - 1,500 Hz

Sound Pressure Level

87 dB/W (1m)

Rated Input Power

75W

Max Input Power

150W

Net Dimensions

6.3 x 13.8 x 11.0 inches
(160 x 350 x 280 mm)

Net Weight

7.0 lbs (3.2 kg)
