Read Two-Digit Addendum
If enabled, the reader will decode the two-digit secondary symbol when
it is scanned with the primary symbol, and add the data to the end of
the transmission. If not, any two-digit secondary symbol will be
ignored.
G2I for Read Two-Digit Addendum
G2J for Do Not Read Two-Digit Addendum
Read Five-Digit Addendum
This option operates in the same manner as the Read Two Digit
Addendum option except it enables the reading of a five digit second-
ary symbol.
G2K for Read Five-Digit Addendum
G2L for Do Not Read Five-Digit Addendum
Addendum Required
If a two or five-digit addendum is enabled, then enabling this option
will require an addendum be present before a good read is registered. If
not, then symbols with and without the addendum will be accepted.
G2M for Addendum Required
G2N for Addendum Not Required
Add Separator Space
This option is used with the Two and Five-Digit Addendum options. If
enabled, an ASCII space character is inserted between the data de-
coded from the primary UPC symbol and the addendum symbol.
G2O to Add Space Separator
G2P to Not Add Space Separator
Magnetic Stripe Selections
The Omni reader can accept and decode data read from a magnetic
stripe. The parameters for reading the magnetic data can be pro-
grammed independently from any of the bar code selections.
1. Enter RETAIL BAR CODE SETUP MODE by typing /E/D/FH.
2. Press .
3. Type the one or two-character code for the selection you wish to
make.
4. Save your selection by pressing .
5. To review the current setting, enter HY.
6. Exit the group setup mode by entering HZ.
7. To reset the terminal type setting to default, enter HX.
